Light Electricity Integration System

  • 　　　　　　　　　　　　
    　　　　　　　　　　　　

    System principle

    　　Tubular daylighting system is mainly the collection of daytime natural light for indoor lighting, in order to solve the problem of tubular daylighting system can’t be lighting at night, to meet customer and market demand, combined with the light pipe lighting system products conform to the students, such as photoelectric Integrated systems, guided light integration of photovoltaic, intelligent photographic control systems.

    Photoelectric integration system
    　　The power lighting system is installed in the “SUNTUBE” Tubular daylighting system to realize daytime use of natural light and night light through LED, so as to achieve the normal operation of the system 24 hours a day. Combined with the following three forms of selective control to meet customer needs in different occasions.

    1.Optical Induction Control System
    Applies to: office space, factories, shopping malls and so on.

    2.Microwave Induction Control System
    Applies to: underground garage, railway station, subway and so on.

    3.Combined Control System of Optical Induction and Microwave Induction
    Applies to: exhibition halls, zoos, botanical gardens and so on.






    System Components
    Light collector
      "SUNTUBE" crystal light collection system has a patent of appearance design（patent of appearance design no. : ZL 2013 3 0314424.1），The top five directions according to the uniform distribution of 15 °, can prevent the dust, self-cleaning effect.
    Inside the light collection system at the top of the thread of direct reduction by scattered light, at noon the light evenly; Lateral intercostal stripe refraction effect, can be in the morning or evening diffuse light refraction collection.
    Technical parameters of diamond concentrator
    　　　　　　　　
    Light guide tube
    　　"SUNTUBE” is still using the tube with corrosion resistance and high reflectivity, five special coating to ensure the efficient transmission of light and stability, with 0º-90º bend, flexible turning, not affected by the building structure
    　　　　　　　　

    Technical parameters of light guide tube

    　　　　　　　
    Diffuser
    　　Diffuser having a strong transmission and scattering properties, natural light can enter the system to redistribute and uniformly distributed in the room.

    Technical parameters of diffuser
    　　　　　　　
     "SUNTUBE" Diffuser Types
    Lattice diffuser Prismatic Diffuser Thread Diffuser Lampshade Diffuser
    Unique physical structure is conducive to the secondary distribution of incident light, light diffuse uniformity, no glare, bright does not glare beautiful arc shape outline clear, bright and strong consistency Fresnel lens array, a strong three-dimensional, beautiful visual bright Formed outside the arc, beautiful fashion, there is more for high-quality ceiling workplace.
    LED
    　　LED lamps will be installed in the diffuser ring, natural lighting and artificial lighting combined to save space for the ceiling, while at night the light emitted by the lamp can also be used to do outdoor landscape lights.

    　　　　　　　　　　
    Technical parameters of system
    　　　　　　　​
     Feature purpose

    1.Saving electric lighting costs.


    2.Improve the indoor light environment.


    3.Meet the new green building scoring standards.
    4.Enjoy the green healthy sunshine

    Dust mask to add anti-UV ingredients, can effectively filter 99.9% of the UV, the diffuser evenly distributed in the room to optimize the indoor working and living environment, improve work efficiency, reduce fatigue, physical and mental health.
    System Benefits
    1.Saving installation space.


    2.Easy installation and maintenance.
         		 3.Real security green products.


    4.Light uniform and elegant appearance.
